Klipsch Professional Speaker SUB ICSW8T2

Category : In-Ceiling Speakers
SKU : ICSW8T2

$649.00 CAD

Built from the inside out for performance and durability the IC-SW-8T2 packs a lot of substance into commercial sound system.

  • High sensitivity and power handling
  • Extended powerful bass
  • Very high output capability
  • Transformerless 70V/100V w/ 2 wattage settings single-input 4-ohm or dual-input 8-ohm operation
  • ABS baffle with removable paintable powder-coated aluminum grille

UL approved for 1480/2043

Most distributed audio systems are plagued with thin-sounding performances but the new IC-SW-8T2 in-ceiling subwoofer changes everything. Engineered for music reinforcement applications these unobtrusive easy-to-install loudspeakers feature a transformer-less design for 70V/100V distributed-line systems with two wattage settings. Since transformers severely limit a subwoofer's capabilities this unique design is the perfect solution when building a great sounding commercial system.

The IC-SW-8T2 adds more dimension to any in-ceiling configuration by using an 8-inch woofer 8-inch drone polypropylene cones and high-temperature voice coils in the active driver. While most subwoofers use a port to increase output the IC-SW-8T2 employs a bandpass design that utilizes a passive radiator. This eliminates a lot of the distortion and removes turbulence that is often present in ported designs. Maximum continuous output is a remarkable 111dB. And since AES rated sensitivity is 92dB adequate levels can be achieved with modest amplifier power using the IC-SW-8T2.

Other key features of the IC-SW-8T2 include the ability to easily switch from low impedance to high impedance distributed-line applications as well as mono and two-channel inputs in low impedance modes. This durable subwoofer has an ABS plastic baffle formed steel back can and a four-point terminal strip input connector and is UL 2043 and 1480 certified.

The IC-SW-8T2 is shipped complete with a tile bridge for installation in a suspended ceiling or wherever additional reinforcement of the ceiling material is required. A mudring kit (part # 061347) is also available for drywall ceiling installations.



Specifications
FREQUENCY RESPONSE:50-130 Hz +/- 4 dB
SENSITIVITY: 92 dB 2.83 V/1M
POWER HANDLING: 150 watts (27 V) cont.
MAXIMUM ACOUSTIC OUTPUT:111 dB @ 1M
NOMINAL IMPEDANCE:6 ohms, min 4.9 ohms, switch set to mono or stereo position
ENCLOSURE TUNING: Bandpass via an 8" Drone
INPUT CONNECTIONS: Terminal Strip
CUTOUT DIMENSIONS:12.5" (31.75cm) diameter
OVERALL DEPTH:13" (33.02 cm)
MOUNTING DEPTH: 12.625" (32.07 cm)
OVERALL WIDTH:14.2" (36.07 cm) diameter
THRU HOLE WIDTH: 12.4" (31.50 cm) diameter
WEIGHT: 23 lbs.
FINISHES: White
TRANSDUCERS: 8" Woofer AND 8" Drone
TRANSFORMER TAPS: 70V: 60W, 30W 100V: 120W, 60W
BUILT FROM:2008
